Marq MQ2TB1 Automatic Case Sealer with Nordson Glue System

The Marq MQ2TB1 Fully Automatic Case Sealer is a high-speed packaging system designed for efficient and reliable corrugated case sealing. Equipped with a Nordson HM IV hot melt glue application system, this machine automatically seals both the top and bottom major flaps while handling a continuous flow of cases.

The system features an extended compression hold-down roller section to ensure strong, consistent seals and includes an automatic indexing gate for smooth product flow. A top-back minor flap tucker helps prepare cases for sealing, while quick-adjust handwheels allow for fast and simple size changeovers.

Designed for industrial packaging environments, this machine processes up to 20 cases per minute and accommodates a wide range of case sizes. All moving components are properly OSHA guarded for operator safety.

Prior to shipment, the machine and glue application system will be shop tested, thoroughly cleaned, and inspected to ensure excellent running condition.

Features

▲ Marq Model MQ2TB1 fully automatic case sealer

▲ Nordson HM IV hot melt glue system included

▲ Seals both top and bottom major flaps

▲ Extended compression hold-down roller section

▲ Automatic indexing gate for continuous case flow

▲ Top-back minor flap tucker

▲ Quick size change adjustments via handwheels

▲ OSHA guarded construction

▲ Rated for up to 20 cases per minute

▲ 230V / 3 Phase electricals

▲ Requires approximately 4 SCFM at 80 PSI compressed air

▲ Shop tested and cleaned prior to shipment

Specifications

Manufacturer: Marq

Model: MQ2TB1

Serial Number: 7220

Glue System: Nordson HM IV Hot Melt System

Electrical Requirements: 230 Volt, 3 Phase

Production Rate: Up to 20 Cases Per Minute

Compressed Air Requirement: 4 SCFM @ 80 PSI

Case Length Range: 8″ to 24″

Case Width Range: 8″ to 22″

Case Height Range: 5.5″ to 16″

Case Orientation: Standard width configuration (box length runs in line with flow direction)
